| Ton | 330 T | |
| Bed L-R | 84.65 in | |
| Bed F-B | 39.37 in | |
| Stroke | 4.92 in | |
| Adjustment | 3.94 in | |
| Shut Height | 21.65 in | |
| Min Speed | 50 spm | 50 strokes/min. |
| Max Speed | 120 spm | 120 strokes/min. |
| Windows | 37 in |
Capacity: 330 Ton
Stroke: 4.92"
Adjustment: 3.94"
Die Height: 21.65"
Bed Area: 84.65" lr x 39.37" fb
Bolster Thickness: 9.84"
Ram Area: 84.65" lr x 35.43" fb
Speed: 50 - 120 SPM (variable speed)
Windows: 35" Wide x 25.5" High
Inch / Single / Continuous Modes
Dual Palm Buttons
Air Clutch & Brake
Air Counter Balances
8 Point Gibbing
Recirculating Lubrication
Front and Rear Die Doors
Light Curtains (Front Only)
